Prism Basin Taps

Made for the Prism range, the Bristan Prism Basin Taps (PM1/2C) are practical basin taps with a clear design identity. They give separate hot and cold water control for traditional basin installations. Key features include they are supplied as a pair and are only available in chrome plated finish as shown., main construction material: brass, handle type: tubular lever.

- Give separate hot and cold water control for traditional basin installations
- Crisp geometric styling for modern bathrooms
- They are supplied as a pair and are only available in chrome plated finish as shown.
- Main Construction Material: Brass
- Mount Type: Deck
- Handle Type: Tubular Lever
- Valve/Cartridge Type: 1/2" Ceramic Disc Valve ﾼ Turn
- Long life and easy to use 1/4 turn ceramic disc valves
- Easy-to-use lever handles
- Chrome finish
- Ceramic disc valve technology
- Lever handle operation
- Brass construction
- Metal back nuts for secure fitting

Specifications
- Measurements: (height) 80mm (depth) 110mm
- Spout Measurements: (projection) 75mm (height) 40mm
- Base Diameter: 45mm
- Connection Inlet: 1/2" BSP
- Connection Outlet: M24 Flow Straightener
- Minimum Dynamic Pressure (bar): 0.2 bar
- Maximum Dynamic Pressure (bar): 5 bar
- Maximum Hot Water Temperature ﾰ: 65ﾰ
- Maximum Static Pressure (bar): 10 bar
- Flow Rate (l/min)

Flow Rates
- 0.2 bar: 7.3 (l/min)
- 0.5 bar: 11.6 (l/min)
- 1 bar: 16.4 (l/min)
- 2 bar: 23.2 (l/min)
- 3 bar: 28.4 (l/min)
- 5 bar: 36.7 (l/min)
