Tangram Single Hole Bath Filler Brushed Brass

The Bristan Tangram Single Hole Bath Filler Brushed Brass (TAN1HBFBB) combines Bristan bathroom brassware styling with the practical function of a bath filler tap. It fills the bath cleanly while coordinating with matching basin brassware, making it suitable for bathroom upgrades and new installations. Key features include lever: single lever handle, finish: brushed brass, material: solid brass.

- Fills the bath cleanly while coordinating with matching basin brassware
- Bristan bathroom brassware styling
- Lever: Single lever handle
- Finish: Brushed brass
- Material: Solid brass
- Long life ceramic cartridge for added durability and smooth control.
- Flexible tails included for easy installation; complete the look with a matching Bristan waste
- Also available in black and chrome.
- Chrome finish
- Ceramic disc valve technology
- Lever handle operation
- Brass construction
- Flexible tails included

Specifications
- Measurements: (Height) 160mm (Depth) 150mm
- Spout Dimensions: (Projection) 100mm, (Height) 110mm
- Base Diameter: 55mm
- Connection Inlet: 1/2" BSP Flexible Tails
- Connection Outlet: M24 Recessed Honeycomb Aerator
- Valve/Cartridge Type: 40mm Upper Seal Cartridge
- Minimum Operating Pressure: 1.0 bar (High pressure)
- Maximum Operating Pressure: 5 bar
- Maximum Hot Water Temperature oC: 60
- Maximum Statis Pressure (bar): 10 bar
- Flow Rates (l/min)

Flow Rates
- 1 bar - 15 (l/min)
- 2 bar - 21.1 (l/min)
- 3 bar - 25.2 (l/min)
- 5 bar - 34.2 (l/min) (l/min)
