Tangram Single Hole Bath Filler Matt Black

For a coordinated bathroom brassware scheme, the Bristan Tangram Single Hole Bath Filler Matt Black (TAN1HBFBLK) provides a dependable bath filler tap. It fills the bath cleanly while coordinating with matching basin brassware. Key features include lever: single lever handle, material: solid brass, long life ceramic cartridge for added durability and smooth control..

- Fills the bath cleanly while coordinating with matching basin brassware
- Bristan bathroom brassware styling
- Lever: Single lever handle
- Finish: Matt black
- Material: Solid brass
- Long life ceramic cartridge for added durability and smooth control.
- Flexible tails included for easy installation; complete the look with a matching Bristan waste
- Also available in brass and chrome.
- Chrome finish
- Ceramic disc valve technology
- Lever handle operation
- Brass construction
- Flexible tails included

Specifications
- Measurements: (Height) 160mm (Depth) 150mm
- Spout Dimensions: (Projection) 100mm, (Height) 110mm
- Base Diameter: 55mm
- Connection Inlet: 1/2" BSP Flexible Tails
- Connection Outlet: M24 Recessed Honeycomb Aerator
- Valve/Cartridge Type: 40mm Upper Seal Cartridge
- Minimum Operating Pressure: 1.0 bar (High pressure)
- Flow Rates (l/min)

Flow Rates
- 1 bar - 15 (l/min)
- 2 bar - 21.1 (l/min)
- 3 bar - 25.2 (l/min)
- 5 bar - 34.2 (l/min)
