Smile Bath Shower Mixer
For a coordinated bathroom brassware scheme, the Bristan Smile Bath Shower Mixer (SMBSMC) provides a dependable bath shower mixer tap. It combines bath filling with a shower handset for flexible bathing and rinsing. Key features include main construction material: brass, handle type: lever, finish: chrome.
- Combines bath filling with a shower handset for flexible bathing and rinsing
- Simple rounded styling for family bathrooms
- Main Construction Material: Brass
- Mount Type: Deck
- Handle Type: Lever
- Finish: Chrome
- Valve/Cartridge Type: 1/4 Turn 3/4" Ceramic Disk Valve
- Long life and easy to use 1/4 turn ceramic disc valves
- Chrome finish
- Ceramic disc valve technology
- Lever handle operation
- Brass construction
- Metal back nuts for secure fitting
- Shower handset included
Specifications
- Measurements: (Height) 125mm (Width) 230mm (Depth) 145mm
- Spout Dimensions: (Projection) 120mm, (Height) 45mm
- Handset Dimensions: (height) 185mm (width) 30mm
- Connection Inlet: 3/4" BSP
- Connection Outlet: G ï¾½"
- Minimum Operating Pressure: 0.2 bar
- Maximum Dynamic Pressure: 5.0 bar
- Maximum Hot Water Temperature ï¾°: 65ï¾°
- Maximum Static Pressure (bar): 10 bar
- Flow Rates (l/min) through Handset
- Flow Rates (l/min) through Bath Filler
Flow Rates
- 0.2 bar - 5.2 (l/min)
- 0.5 bar - 8.2 (l/min)
- 1 bar - 11.6 (l/min)
- 2 bar - 16.4 (l/min)
- 3 bar - 20.1 (l/min)
- 5 bar - 25.9 (l/min)
- 0.2 bar - 18.4 (l/min)
| Approvals | WRAS Approved |
|---|---|
| Availability | in stock |
| Basic Dimensions | 120mm height, 108mm projection |
| EAN Number | 5014868014234 |
| Guarantee | Lifetime |
| Pipe Centres | Fixed at 180mm |
| Manufacturer | Bristan |
| Valve Technology | Ceramic Disc |
| Return period | 14 days |
